19-KB1N-0
The Fire Magic Classic Power Burner delivers concentrated high heat with a combined output up to 60,000 BTU, engineered for wok cooking, searing and turkey frying. Constructed from commercial-grade stainless steel with a fitted lid and stainless cooking grid, the unit resists corrosion and is serviceable in outdoor conditions. Dual-burner architecture provides an inner burner adjustable from 3,000–15,000 BTU and an outer burner reaching up to 45,000 BTU for precise temperature control. A 10-inch diameter flame collimator focuses heat into the center 25% of the surface, producing up to 190 BTU per square inch for rapid high-heat applications. Battery-powered ignition accepts a standard 9V cell for reliable startup and isolates electrical requirements to the ignition alone. Cut-out dimensions measure 19 in W x 18.75 in D x 11.5 in H and the unit ships at approximately 62 lb, simplifying built-in integration and installation planning. The design matches Fire Magic Classic and Legacy grill series and accepts standard connector kits and vinyl covers for complete outdoor kitchen integration. Serviceable components and precision controls make this power burner a professional-grade accessory that expands the capabilities of any outdoor cooking setup.
Key Features:
- Stainless Steel Construction: High-quality stainless steel ensures long-lasting performance and resistance to the elements. Includes a stainless steel lid to protect the burner when not in use.
- Unmatched Heat Output: Delivers an impressive range of 3,000 to 60,000 BTUs, catering to a wide array of cooking needs. The left knob controls the inner burner with 3,000 to 15,000 BTUs, while the larger right knob manages the outer burner, reaching up to 45,000 BTUs
- Heat Concentrating Flame Collimator: The 10" diameter collimator focuses intense heat in the center 25% of the unit, perfect for tasks requiring up to 190 BTU/sq. in., such as wok cooking and turkey frying.
- Easy Operation: The battery-powered ignition doesn't require any other connections besides the gas line.
Specifications
| Material | Commercial-grade stainless steel construction with stainless lid and stainless cooking grid |
| Total BTU Output | Up to 60,000 BTU (Inner burner 3,000–15,000 BTU; Outer burner up to 45,000 BTU) |
| Heat Collimator | 10 in diameter flame collimator concentrating heat in center 25% of unit; up to 190 BTU/sq in |
| Ignition | Battery-powered 9V ignition (9V battery not included) |
| Number of Burners | Two (2) burners |
| Cut-Out / Mounting Dimensions | 19 in W x 18.75 in D x 11.5 in H (cut-out dimensions for built-in installation) |
| Shipping Weight | Approximately 62 lb |
| Gas Options | Available for Natural Gas or Propane (select at time of order) |
Downloads:
Warranty Highlights
Lifetime Warranty:
Cast stainless steel burners, choice stainless steel U-shaped burners, Diamond Sear & stainless steel rod cooking grids, and stainless steel housings are warranted for as long as you own your Fire Magic Grill.
Fifteen (15) Year Warranty:
Brass valves, inner liners, manifold assemblies, porcelain housings (including ovens and barbecue faces), and backburner assemblies (except ignition parts)
Ten (10) Year Warranty:
Electric grills, including stainless steel cooking grids, and housings. Built-in griddles (except ignition system)
Five (5) Year Warranty:
Flavor grids, infrared burners in the grill, charcoal stainless steel grills and smokers (except for the charcoal pan, charcoal grid, wood pellet screen, thermometer And ashtray; which are warranted for one [1] year)
Three (3) Year Warranty:
Side burners and all other Fire Magic grill components (except ignition systems and electrical parts)
One (1) Year Warranty:
Ignition systems (except batteries), electronic components (including lights and thermometers), and grill accessories.
Thirty (30) Days Warranty:
Replacement parts carry a 30 day warranty from the date of purchase.
The Fire Magic Classic Power Burner delivers concentrated high heat with a combined output up to 60,000 BTU, engineered for wok cooking, searing and turkey frying. Constructed from commercial-grade stainless steel with a fitted lid and stainless cooking grid, the unit resists corrosion and is serviceable in outdoor conditions. Dual-burner architecture provides an inner burner adjustable from 3,000–15,000 BTU and an outer burner reaching up to 45,000 BTU for precise temperature control. A 10-inch diameter flame collimator focuses heat into the center 25% of the surface, producing up to 190 BTU per square inch for rapid high-heat applications. Battery-powered ignition accepts a standard 9V cell for reliable startup and isolates electrical requirements to the ignition alone. Cut-out dimensions measure 19 in W x 18.75 in D x 11.5 in H and the unit ships at approximately 62 lb, simplifying built-in integration and installation planning. The design matches Fire Magic Classic and Legacy grill series and accepts standard connector kits and vinyl covers for complete outdoor kitchen integration. Serviceable components and precision controls make this power burner a professional-grade accessory that expands the capabilities of any outdoor cooking setup.
Key Features:
- Stainless Steel Construction: High-quality stainless steel ensures long-lasting performance and resistance to the elements. Includes a stainless steel lid to protect the burner when not in use.
- Unmatched Heat Output: Delivers an impressive range of 3,000 to 60,000 BTUs, catering to a wide array of cooking needs. The left knob controls the inner burner with 3,000 to 15,000 BTUs, while the larger right knob manages the outer burner, reaching up to 45,000 BTUs
- Heat Concentrating Flame Collimator: The 10" diameter collimator focuses intense heat in the center 25% of the unit, perfect for tasks requiring up to 190 BTU/sq. in., such as wok cooking and turkey frying.
- Easy Operation: The battery-powered ignition doesn't require any other connections besides the gas line.
Specifications
| Material | Commercial-grade stainless steel construction with stainless lid and stainless cooking grid |
| Total BTU Output | Up to 60,000 BTU (Inner burner 3,000–15,000 BTU; Outer burner up to 45,000 BTU) |
| Heat Collimator | 10 in diameter flame collimator concentrating heat in center 25% of unit; up to 190 BTU/sq in |
| Ignition | Battery-powered 9V ignition (9V battery not included) |
| Number of Burners | Two (2) burners |
| Cut-Out / Mounting Dimensions | 19 in W x 18.75 in D x 11.5 in H (cut-out dimensions for built-in installation) |
| Shipping Weight | Approximately 62 lb |
| Gas Options | Available for Natural Gas or Propane (select at time of order) |
Downloads:
Fire Magic Product Specification Brochure Fire Magic Gourmet Power Burner Slide-In InstructionsFire Magic Catalog
Warranty Highlights
Lifetime Warranty:
Cast stainless steel burners, choice stainless steel U-shaped burners, Diamond Sear & stainless steel rod cooking grids, and stainless steel housings are warranted for as long as you own your Fire Magic Grill.
Fifteen (15) Year Warranty:
Brass valves, inner liners, manifold assemblies, porcelain housings (including ovens and barbecue faces), and backburner assemblies (except ignition parts)
Ten (10) Year Warranty:
Electric grills, including stainless steel cooking grids, and housings. Built-in griddles (except ignition system)
Five (5) Year Warranty:
Flavor grids, infrared burners in the grill, charcoal stainless steel grills and smokers (except for the charcoal pan, charcoal grid, wood pellet screen, thermometer And ashtray; which are warranted for one [1] year)
Three (3) Year Warranty:
Side burners and all other Fire Magic grill components (except ignition systems and electrical parts)
One (1) Year Warranty:
Ignition systems (except batteries), electronic components (including lights and thermometers), and grill accessories.
Thirty (30) Days Warranty:
Replacement parts carry a 30 day warranty from the date of purchase.
